Gewiss Residual Current Circuit Breaker GWD4132
Manufacturer: Gewiss
Designation: Residual Current Circuit Breaker 4-p, 40A, 30mA
Type: GWD4132
Number of Poles: 4
Rated Voltage: 400 V
Rated Current: 40 A
Rated Residual Current: 0.03 A
Rated Insulation Voltage Ui: 500 V
Rated Impulse Voltage Resistance Uimp: 4 kV
Power Loss: 11.7 W
Mounting Type: DIN Rail
Residual Current Type: A
Selective Type: No
Short Time Delayed Type: No
Short-Circuit Strength (Icw): 10 kA
Surge Current Strength: 0.25 kA
Voltage Type: AC
With Locking Device: No
Frequency: 50/60 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Division Units: 4
Installation Depth: 72 mm
Ambient Temperature During Operation: -25..40 °C
Degree of Pollution: 2
Connectable Conductor Cross-Section Multi-Wire: 35 mm²
Connectable Conductor Cross-Section Single-Wire: 35 mm²
Explosion Protected: No
The residual current circuit breaker is a network voltage-independent residual current device (RCCB) according to EN61008-1. It is suitable for retrofitting 2 additional devices and/or combinations with modules for automatic reset (Restart). The switch lever can be sealed in both the ON and OFF positions or locked with a lever lock (accessory to be ordered separately) for a padlock.
It features an integrated residual current indicator and a foldable labeling plate. Connection (max): 35 mm² with insulated plug-in protection. The connection screws can be equipped with a sealable cover (accessory to be ordered separately).
EAN: 8011564824294.
Circuit breaker type | Fault current circuit breaker |
Length | 72 mm |
Width | 4 mm |
number of poles | 4 |
Mounting type | Top-hat rail |
Item number | 23047917 |
Manufacturer | Gewiss |
Category | Residual-current device |
Manufacturer no. | GWD4132 |
Release date | 9.11.2022 |
Circuit breaker type | Fault current circuit breaker |
Mounting type | Top-hat rail |
number of poles | 4 |
Tripping characteristic | A |
Rated current | 40 A |
Rated current | 0.03 A |
Rated voltage | 400 V |
voltage type | AC |
Rated insulation voltage Ui | 500 V |
Residual current (rated differential current) | 0.30 A |
Protection type (IP code) | IP20 |
Country of origin | Portugal |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 Piece |
Length | 72 mm |
Width | 4 mm |
Length | 10 cm |
Width | 8 cm |
Height | 7 cm |
Weight | 330 g |
