Hager energy monitoring server HTG411H

Manufacturer: Hager
Designation: Energy monitoring server + micro SD card
Type: HTG411H
KNX bus system: No
KNX radio bus system: No
Radio bus system: No
LON bus system: No
Powernet bus system: No
Other bus systems: None
Bidirectional radio: No
Design: Ethernet interface
Mounting type: REG
Width in division units: 6
Dismantling protection: No
With LED display: Yes
Updatable: Yes
Operating voltage: 24 V
Voltage type: DC
Power consumption: 7 W
Protocol: TCP/IP
Provider dependent: No
Visualization: Yes
Web server: Yes
Radio interface: No
IR interface: No
Protection class (IP): IP20

The energy monitoring server agardio.manager, REG, 6 PLE, micro SD card, collects, stores, and processes the measured values of the connected products. This data can be viewed through the integrated LAN interface and the web server functionality using various internet browsers on different devices (PC, notebook, tablet) over the network and can be exported in CSV format.

With the email notification feature, there is the possibility to forward alarm messages (threshold exceedances, fault/error messages, etc.). The device supports evaluation according to DIN VDE 0100-801 and visualizes this. The communication basis between the energy monitoring server and the measuring devices is ModbusRTU (master-slave principle).

Thanks to the product catalog stored in the server, quick parameterization is possible without the use of Modbus mapping tables. The energy monitoring server has two digital inputs (e.g., for connecting pulse outputs from gas and water meters), two analog inputs 4 to 20 mA, one input for PT100 temperature sensors, one potential-free relay contact (output), and one output 0-10 V.

EAN: 3250613113902.
