OBO Bettermann PV System Solution PVG-C1000S100

Manufacturer: OBO Bettermann
Description: PV system solution in enclosure
Type: PVG-C1000S100
Number of inputs: 1
Max. voltage measurement range DC: 1000 V
Width: 190 mm
Height: 150 mm
Depth: 94 mm
String protection: none
Protection class (IP): IP66
Impact resistance: IK05
Test class Type 1: no
Test class Type 2: yes
Test class Type 3: no
Monitoring function: no
Operating temperature: -5..60 °C
Max. output current: 30 A
Color: gray
Number of cable entries: 4
Type of entry: other

OBO Bettermann PV System Solution PVG-C1000S100: further details
System solution Type 2 with MC4 connector for PV inverters with 1 MPP tracker. Varistor surge protector, pluggable with disconnection device in fault-resistant Y-circuit according to VDE 0100-712 (50539-12). Low DC protection level: < 4.0 kV (Uoc max = 1000V DC with V20-C/0-500PV). One PV string input (MC4 connector) to one MPP inverter input, up to 30A DC per terminal, pre-assembled in polycarbonate enclosure (IP66), UV resistant for outdoor use. For DC protection of inverters in PV systems. Additional measures may be necessary in case of condensation risk due to wind, ice, temperature, or sun!
EAN: 4012196816095.
