Phoenix Contact Surge arrester Ü
More than 10 pieces in stock at supplier
Product details
The surge protection arrester from Phoenix Contact is a highly advanced device specifically designed for use in 2-pole isolated and grounded PV DC systems with a nominal voltage of 600 V DC. This product provides effective protection against lightning currents and overvoltages that can occur in electrical systems. The arrester is suitable for DIN rail mounting and features a 3-pole base element that allows for easy installation. The three plug-in, temperature-monitored protective elements ensure reliable operation and safety. Additionally, the device offers a status indication at each plug, facilitating monitoring and maintenance. With a nominal discharge current of 15 kA and a lightning discharge current of 5 kA, this surge protection arrester is a robust solution for the demands of modern photovoltaic systems.
- Type 1 surge arrester for PV DC systems
- Temperature-monitored protective elements for enhanced safety
- Status indication at each plug for easy monitoring
- Nominal discharge current of 15 kA for effective protection
- Suitable for DIN rail mounting, simplifying installation.
Surge protection type | Surge arrester |
Number of conductors | 2 x |
Test class | Type 1 |
Item number | 8461873 |
Manufacturer | Phoenix Contact |
Category | Surge protection |
Manufacturer no. | 2801163 |
Release date | 21.4.2018 |
External links |
Colour | Black |
Exact colour description | Black |
Material group | Plastic |
Material | Polyamide |
Surge protection type | Surge arrester |
Number of conductors | 2 x |
Lightning impulse current | 5 kA |
Rated leakage surge current | 15 kA |
Nominal voltage | 600 V |
Protection level | 2.60 V |
Test class | Type 1 |
Protection type (IP code) | IP20 |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 0.07 m |
Width | 0.05 m |
Height | 0.09 m |
Weight | 365.40 g |
