Schneider Electric Compact Circuit Breaker C10R32M050

Manufacturer: Schneider Electric
Designation: Compact Circuit Breaker ComPacT NSX100R with Type: C10R32M050
Overload Release Current Setting: 25..50 A
Setting Range of Instantaneous Short-Circuit Release: 750 A
With Thermal Protection: yes
Phase Failure Sensitive: yes
Release Technology: electronic
Rated Operating Voltage: 690 V
Rated Continuous Current Iu: 50 A
Connection Type Main Circuit: Screw Connection
Design of Actuating Element: other
Device Type: Built-in Device Fixed Installation Technology
With Integrated Auxiliary Switch: no
With Integrated Undervoltage Release: no
Number of Poles: 3
Rated Short-Circuit Breaking Current Icu at 400 V, AC: 200 kA
Protection Class (IP): IP40
Height: 161 mm
Width: 105 mm
Depth: 86 mm

Schneider Electric Compact Circuit Breaker C10R32M050: Additional Details
The ComPacT NSX100R is a complete 3P 3d circuit breaker designed for fixed installation, optimized for space requirements and breaking capacity. It is an ideal choice for motor protection applications. The breaking capacity (Icu) is 200 kA at 415 VAC 50/60 Hz and 45 kA at 690 VAC 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product features an electronic release device MicroLogic 2.2 M with a rated current of 50 A. The MicroLogic 2.2 M release device offers adjustable long-time and short-time protection functions along with fixed instantaneous protection. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional features and accessories. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications. The ComPacT NSX100R is part of Schneider Electric's EcoStruxure Power architecture.
