Schneider Electric I/O Module METSEPM2KANLGIO11

Manufacturer: Schneider Electric
Description: I/O Module Analog, 1 Input/1 Output
Type: METSEPM2KANLGIO11
Number of Analog Inputs: 1
Number of Analog Outputs: 1
Configurable Analog Inputs: yes
Configurable Analog Outputs: yes
Input, Current: yes
Input, Voltage: no
Input, Resistance: no
Input, Resistance Thermometer: no
Input, Thermocouple: no
Configurable Input Signal: no
Output, Current: yes
Output, Voltage: no
Configurable Output Signal: no
Type of Electrical Connection: Screw Terminal
Suitable for Safety Functions: no
Associated Equipment (Ex ia): no
Associated Equipment (Ex ib): no
Explosion Protection Category for Gas: none
Explosion Protection Category for Dust: none
Width: 90.5 mm
Height: 53 mm
Depth: 14.6 mm

Schneider Electric I/O Module METSEPM2KANLGIO11: further details
Analog I/O option module compatible with PowerLogic PM2x30 devices, providing additional analog inputs and outputs. 1 Analog input (4-20 mA). 1 Analog output (4-20 mA) for currents, voltages, power, power factor. Analog inputs and outputs are set up and configured via the ION Setup software. The option modules are mounted on the back of the meter and are used to connect the control voltage and the interface bus. The PowerLogic PM2x30 devices allow a maximum of 1 I/O option module per meter.
EAN: 3606480800214.
