The Intel Wi-Fi 6 AX210 is a WLAN and Bluetooth 5.2 adapter in the form of an M.2 2230 module with an A-E key. The adapter simply plugs into an available M.2 slot, enhancing any laptop or PC with fast WLAN and Bluetooth connectivity.

The integrated Intel AX210 chipset enables transmission in both the 2.4 and 5 GHz bands and supports the new 802.11ax standard. It achieves transmission speeds of up to 2.402 Gb/s (5 GHz). With support for 2x2 Wi-Fi 6 technology, the adapter has been certified by the Wi-Fi Alliance with the Wi-Fi 6 certification. In addition to MU-MIMO (Multi-User MIMO), the Wi-Fi 6 AX210 also supports OFDMA (Orthogonal Frequency-Division Multiple Access).

The Intel Wi-Fi 6 AX210 module is also backward compatible with many common WLAN standards: IEEE 802.11 a/b/g/n/ac/ax. Current encryption techniques such as WPA/WPA2/WPA3 ensure high security.

Note: The antenna required for reception is not included in the package and must be purchased separately.

Technical details:

• Form factor: M.2 2230
• Connection: M.2/A-E Key
• Additional connectors: 2x MHF/U.FL antenna connector
• WLAN:
• Standards: IEEE 802.11a/b/g/n/ac/ax
• Frequency bands: 2.4 GHz, 5 GHz, 6 GHz
• Transmission rate: 2.402 Gb/s (5GHz), 574 Mb/s (2.4 GHz)
• Security: WEP 64/128 Bit, WPA, WPA2, WPA3, TKIP, 128-bit, AES-CCMP, 256-bit AES-GCMP
• Features: MU-MIMO, OFDMA
• Bluetooth: 5.2.
