ABB Stotz S&J RCD F202B+16/0,3 Manufacturer :ABB Stotz S&J Description :RCD 2P,TypeB+,16A,300mA Type :F202B+16/0,3 No. of poles :2 Rated voltage :230 V Rated current :16 A Rated residual current :0.3 A Rated insulation voltage Ui :500 V Rated impulse withstand voltage Uimp :4 kV Mounting type :DIN rail Residual current type :B+ Selective type :no Short-time delay type :yes Short-circuit withstand rating (Icw) :1 kA Surge withstand rating :3 kA Voltage type :AC With interlocking device :yes Frequency :50 Hz Additional devices possible :yes Protection class (IP) :IP2X Width in pitch units :2 Mounting depth :69 mm Ambient temperature during operation :-25..55 °C Degree of contamination :2 Connectable stranded conductor cross-section :0..25 mm² Connectable conductor cross-section solid :25 mm² Explosion-proof :no ABB Stotz S&J residual current circuit-breaker F202B+16/0,3: further details F200 type B+ for smooth DC residual currents and elevated, preventive fire protection all-current sensitive, 10 ms short-time delayed, impulse current resistant 3 kA Residual current circuit breakers (RCCBs) provide personal and property protection as well as protection against electrically ignited fires in accordance with DIN VDE 0100-410 and DIN VDE 0100-530. The residual-current circuit-breakers of the F200 B+ series guarantee protection in the event of sinusoidal alternating currents, pulsating currents and smooth DC residual currents to earth. As well as fault protection (protection in case of indirect contact), additional protection (with I?n = 30 mA) and fire protection (with I?n = 300 mA). They meet the product standards for RCDs type A IEC/EN 61008-1, 61008-2-1, 61543 (VDE 0664 10, 11, 30) and for type B+ DIN VDE 0664-400. They are mainly used in commercial and industrial applications. The extensive range of accessories offers you everything you need for your installation tasks. The RCCB type B+ detect smooth DC residual currents, react earlier than the RCCB type B with max. 420 mA and have a frequency range of 0 ... 20 kHz for the detection of the residual current. Thus, they offer superior, preventive fire protection (extended fire protection according to DIN VDE 0100-530) for e.g. fire-prone premises and commercial units. , EAN: 8012542058625.
