Busch-Jaeger Touch Sensor 4/8-fold 6127/02-83

Manufacturer: Busch-Jaeger
Designation: 4/8-fold Multifunction Touch Sensor
Type: 6127/02-83
KNX Bus System: yes
KNX Radio Bus System: no
Radio Bus System: no
LON Bus System: no
Powernet Bus System: no
Other Bus Systems: none
Mounting Type: Flush-mounted
With Theft/Dismantling Protection: yes
With Bus Coupling: no
Number of Activation Points: 8
Number of Buttons: 8
With LED Display: no
With Labeling Field: yes
With Display: no
Material: Plastic
Material Quality: Thermoplastic
Surface Protection: Painted
Surface Finish: Matte
Color: Aluminum Silver
RAL Number (similar): 9006
With Room Thermostat: no
With Infrared Sensor: no
Protection Class (IP): IP20
Minimum Depth of Device Box: 33 mm

Further Details:
For Busch Installation Bus® KNX 6120/12-101, 6120/13 and Busch Powernet® KNX 6920/12, 6920/13 and 6920/40. With labeling field. Support for KNX functions through innovative color concept (yellow=Lighting, blue=Shutter, orange=RTR, magenta=Scene, and white=neutral/no function assignment) or standard lighting red/green. Button function: Switching / Dimming / Shutter / Sending value / Light scenes, among others. Transparent labeling sheet with standard symbols included in the delivery. Includes 10 logic channels (light scene actuator, sequence actuator, logic gates, etc.). Platform 63, future® linear, Busch-axcent®: Busch-axcent®, Busch-axcent® pure: KNX, EAN: 4011395140147.
