Gesipa G-BULB Blind Rivets ST/ST 6.4 x 17 Steel 250 Pieces

G-Bulb structural blind rivets ensure a strong, vibration-resistant fastening and are specifically designed to achieve a robust connection with high tensile and shear values. The large dome shape formed at the bottom of the rivets makes them suitable for use in thinner materials.

Description:

• Excellent hole-filling properties
• High clamping force
• Resistant to high tensile and shear forces

Technical Specifications:

• Min. material thickness: 4.5 mm
• Max. material thickness: 7.0 mm
• Drill diameter: 6.7 - 6.9 mm
• Rivet diameter: 6.4 mm
• Length: 17.0 mm
• Head diameter: 13.0 mm
• Rivet material: Steel
• Pin material: Steel
• Head shape: Flat convex head.
