Product details
Gesipa G-BULB Blind Rivets ST/ST 6.4 x 17 Steel 250 Pieces
G-Bulb structural blind rivets ensure a strong, vibration-resistant fastening and are specifically designed to achieve a robust connection with high tensile and shear values. The large dome shape formed at the bottom of the rivets makes them suitable for use in thinner materials.
Description:
- Excellent hole-filling properties
- High clamping force
- Resistant to high tensile and shear forces
Technical Specifications:
- Min. material thickness: 4.5 mm
- Max. material thickness: 7.0 mm
- Drill diameter: 6.7 - 6.9 mm
- Rivet diameter: 6.4 mm
- Length: 17.0 mm
- Head diameter: 13.0 mm
- Rivet material: Steel
- Pin material: Steel
- Head shape: Flat convex head.
Rivet type | Blind rivets |
Length | 17 mm |
Diameter | 6.40 mm |
Item number | 33723783 |
Colour | Silver |
Exact colour description | Galvanized |
Material group | Metal |
Material | Steel |
surface finish | Galvanized |
Rivet type | Blind rivets |
Tensile strength | 8000 N |
Shear force | 10000 N |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 250 Piece |
Length | 17 mm |
Diameter | 6.40 mm |
Length | 14.30 cm |
Width | 9.60 cm |
Height | 11.50 cm |
Weight | 2.73 kg |
