Mersen MERS HH sub-area safeguarding operation
16 ANominal current4
Product details
Mersen Fuse Insert HH 45DB120V16PD
Manufacturer: Mersen
Designation: Fuse Insert HH 6-12kV 16A 292mm
Type: 45DB120V16PD
Rated Current: 16 A
Rated Voltage: 12 kV
Voltage Type: AC
Rated Frequency: 50-60 Hz
Breaking Capacity: 63 kA
Operating Class: Other
Application: Other
Length: 292 mm
Diameter: 56 mm
Performance Category according to IEC 60282-1: Partial Range
With Impact Detector: Yes
Standard: IEC
Tripping Characteristic: Other
Installation Technology: Air
Mersen Fuse Insert HH 45DB120V16PD: Additional Details
Mersen HH fuse inserts have been used for decades for reliable protection in high-voltage switchgear and systems. The Limitor -PD product range complies with the standard according to IEC 60282-1 and VDE 0670 T402 and protects transformers against the effects of short circuits. VDE 0670 T402 defines a fuse range between 6.3A and 160A. For additional performance classes, please visit the product range of Mersen's Limitor -P fuse inserts. Mersen uses the best materials: the melting conductors are made of pure silver, contact caps are made of copper with silver coating, and the fuse body is made of ceramic.
Item number | 33619238 |
Material group | Metal |
Material | Ceramic, Contact caps made of copper with silver coating, Fusible link |
Fuse type | Micro fuse |
Tripping characteristic | Lazy |
Nominal current | 16 A |
breaking capacity | 63000 A |
Nominal voltage | 12 V |
voltage type | AC |
Country of origin | Hungary |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 pcs. |
Width | 56 mm |
Length | 292 mm |
Diameter | 292 mm |
Product Safety |
