Best DeWalt products in the Chop saw + mitre saw category
On this page you'll find a ranking of the best DeWalt products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. DeWalt Battery panel saw brushless, without battery 305 mm 30 mm
2. DeWalt Panel saw DWS777
Very compact and light panel saw with powerful 1,800 Watt motor. Sliding left workpiece stop enables both the safe processing of small workpieces and problem-free inclined cuts. Work even more accurately with the XPS cutting line display. Improved suction, AirLock compatible. Easy machining of large workpieces with highest precision due to internal trombone slide with SKF slide and ball bearings. Face-milled base plate and stop made of high-quality die-cast aluminium. Spindle lock recessed into the housing. Easy transport due to safe locking function of the extension and the saw head.
3. DeWalt Panel saw set
DWS780:
Versatile panel saw with powerful 1,675 watt motor
Electronic speed control for material-specific work
Millimetre-precise cuts thanks to LED-supported cutting line display
Very high cutting capacity of up to 110 x 303 mm
Trouble-free cutting to length of 12 mm squared timber (when using a 20 mm shim)
High-quality bearing of the guide rollers ensures precise cuts up to 345 mm length
Angle of inclination precisely and continuously adjustable
Exact mitre angles can be set quickly and easily via fixed detents
Cutting depth limitation for precise tenoning, notching and grooving
Optimally suited for assembly due to compact dimensions and low weight
DE7023:
Suitable for all panel, cross-cut and mitre saws from DEWALT and other brand manufacturers
Ideal for assembly use due to retractable legs, carrying handle and very low weight
Extendable workpiece supports for a maximum working length of 3.85 m
Torsion-resistant and robust aluminium construction, loadable up to 225 kg
XPS cutting line indicator, 60 tooth HMS saw blade (305 x 30), dust collection bag
Assembly tool
Universal base frame DE7023
2 workpiece supports
Machine mounting set (2 pcs.)
Input power (Watt):1.675 Watt
Idle speed (rpm):1.900 3.800
Mitre adjustment:60° right / 50° left
Inclination adjustment:up to 49° on both sides
Saw blade dimensions (mm):305 x 30
Weight (kg): 24.8
90° / 90° (mm): 110 x 303
90° / 45° (mm): 112 x 211
45° / 90° (mm): 268 x 63
45° / 45° (mm): 63 x 212
Sound pressure level LPA (dB (A)): 93.0
Sound power level LWA (dB (A)): 100.00
K (dB (A)): 3.0
Scope of delivery:
305mm panel saw
XPS cutting line indicator, 60 tooth HMS saw blade (305 x 30), dust collection bag,
assembly tool
Universal base frame DE7023
2 workpiece supports
Machine mounting set (2 pcs.)
Technical data:
Input power (watts): 1,675 watts
Idle speed (rpm): 1.900 3.800
Mitre adjustment: 60° right / 50° left
Inclination adjustment on both sides: up to 49
Saw blade dimensions (mm): 305 x 30
Weight (kg): 24,8
Cutting range at:
90° / 90° (mm): 110 x 303
90° / 45° (mm): 112 x 211
45° / 90° (mm): 268 x 63
45° / 45° (mm): 211 x 65
Sound pressure level LPA dB(A): 93.0
Sound power level LWA dB(A): 100.0
Uncertainty factor K dB(A): 3.0
Vibration(m/s²): ?2,5
Uncertainty factor K (m/s²): 1,5
4. DeWalt Panel saw
Very compact and light panel saw with new, powerful 1,400 watt motor.
Large cutting capacity due to internal trombone pull-out with SKF slide and ball bearings
Precise work and perfect illumination of the cutting area thanks to patented XPS cutting line display
Improved suction, AirLock compatible
Face-milled base plate and fence made of high-quality die-cast aluminium and optimised fence design for precise working at all inclination settings
Practical carrying handles, which at the same time significantly enlarge the workpiece support
Simple and quick mitre and tilt adjustment by means of fixed catches for standard angles
Scope of delivery:
Panel saw
24 tooth HMS saw blade
Workpiece clamp and assembly tool
Technical data:
Input power: 1,400 watts
Idle speed: 6,300 min1
Mitre adjustment, left / right: 48 / 48°.
Tilt setting, left: 48
Max. Cutting range at 90°/90° (mm), at 90°/45° (mm), at 45°/90° (mm), at 45°/45° (mm): 250 x 60, 250 x 48, 170 x 60, 170 x 48
Saw blade dimensions: 216 x 30 mm
Weight: 12.0 kg
Triaxial vibration (m/s²): 2,1
Uncertainty factor K1 (m/s²): 1,5
Sound pressure level LPA (dB(A)): 93
Sound power level LWA (dB(A)): 104
Uncertainty factor K (dB(A)): 3.0
5. DeWalt DW743NQS
Adjustable workpiece stop enables precise machining of even small workpieces
High-quality induction motor with very good torque enables maintenance-free use
Safe and easy operation for all applications and set angular positions
Classic table, cross-cut and mitre saw with robust construction and compact dimensions
Triple extraction connection for effective dust extraction as well as versatile use thanks to wide range of accessories
Tool-free conversion from table to cross-cut saw with second operating switch in cross-cut position
Folding mechanism of the stand legs as well as integrated carrying handles for easy transport
Scope of delivery:
Workpiece clamp
Push stick
4 removable legs
Saw blade guard
Rip fence
Assembly tool
Technical data:
Input power: 2,000 watts
Saw blade speed: 2,850 min1
Saw blade: 250 x 30 mm
max. tilt adjustment (left): 45 °
max. mitre adjustment (right/ left): 45/45 °
max. cutting range at 90°/90°: 140 x 68 mm
max. cutting range at 90°/45°: 70 x 95 mm
max. cutting range at 45°/90°: 95 x 70 mm
max. cutting range at 45°/ 45°: 50 x 95 mm
max. cutting range (table saw 90°): 0 70 mm
max. cutting range (table saw 45°): 0 32 mm
Weight: 37,0 kg
Sound pressure level LPA dB(A): 83.0
Sound power level LWA dB(A): 96.0
K dB(A): 3.0
6. DeWalt PRZECINARKA DO METALU 2300W D28710V
The heavy-duty motor is wear-resistant, ensures high overload and longer life. Horizontal handle for better ergonomics and less user fatigue. Quick clamp for less time spent changing the workpiece. Spindle lock for quick and easy disc change. Adjustable spark guard allows the user to control the direction of sparks emitted from the machine. Technical data: Weight 17.5 kg, max. Disc diameter 355 mm Hole diameter 25.4 mm Idling speed 4000 rpm Maximum cutting capacity at 90° angle [square profile] 115 x 115 mm Power source with cable Maximum cutting capacity at 90-angle [rectangular profile] 115 x 130 mm Maximum cutting capacity at 90° angle [L-shaped profile] 120 x 120 mm Maximum cutting capacity at 90° angle [rounded profile] 125 mm Maximum cutting capacity at 45° angle [square profile] 115 x 115 mmt at 45° angle [square profile] 98 x 98 mm Maximum cutting capacity at 45° angle [rectangular profile] 95 x 105 mm Maximum cutting capacity at 45° angle [L-shaped profile] 105 x 105 mm Maximum cutting capacity at 45° angle [rounded profile] 95 x 105 mmt at 45° angle [rounded profile] 115 mm Sound pressure 97.5 dB(A) Sound pressure uncertainty 3 dB(A) Sound power 110.5 dB(A) Sound power uncertainty 3 dB( A) In the set hex key source.
7. DeWalt DW872
