APC SRT2200XLI Smart-UPS SRT 2200 VA

2200 VA, 1980 W, Online double converter UPS
Price in EUR including VAT, free shipping
Delivered between Sat, 24.5. and Wed, 4.6.
5 items in stock at supplier

Product details

Smart UPS, 2200 VA / 1980 W, 2U. Continues to provide power during an outage with up to 1980 watts of output. Surge protection up to 340 joules. Connections: 8x C13, 2x C19, requires a power connection with at least 16 amps. Management: RJ-45 Serial, Smart-Slot, USB. Suitable for rack or tower use. The APC Smart-UPS series protects your critical data with reliable, uninterruptible power supply. The SRT2200XLI offers 2200 VA capacity with a maximum output of 1980 watts. Comprehensive protection. The Smart-UPS On-Line product family provides high value for businesses with demanding power quality requirements through features such as extensive input voltage ranges, highly precise output voltage regulation, frequency regulation, internal bypass, and input power factor correction. In the event of a power failure, the device takes over temporary power supply to ensure a smooth transition to generator operation. After an overload, no fuse needs to be replaced thanks to the resettable circuit breaker. Diligent management. The UPS continuously displays key data such as operating mode, system parameters, and alarms on its LC display. For management via computer, a USB and an RJ-45 serial interface are available. The included PowerChute software allows for convenient monitoring and control, safe operating system shutdown, and innovative energy management features. With the SmartSlot for management cards, you can further expand the device's functions according to your needs. Service options. Diagnostics for early fault detection enable proactive component replacement. The device performs automatic self-tests and notifies you if the power status changes or if a battery needs to be replaced. The battery modules are easy to connect and can be swapped out while the system is running.

Key specifications

Operating time at full load
3.90 min
Model
Desktop
Scope of application
Server room
Plug type
C13C19
Documents
Item number
5713396

General information

Manufacturer
APC
Category
UPS
Manufacturer no.
SRT2200XLI
Release date
5.11.2023

UPS properties

UPS type
Online double converter UPS
Power output
1980 W
Output power capacity
2200 VA
Model
Desktop
shaft type
Sine wave

UPS functions

UPS protection functions
Overvoltage protection

Application range

Scope of application
Server room

Connector plug

Plug type
C13C19

Connections

Connections
USB
USB ports
USB-A

Mains supply properties

input voltage
100 - 275 V
output voltage
230 V
Input frequency
40 / 70 Hz
Output frequency
50 - 60 Hz
overvoltage protection
340 J
Efficiency battery operation
92.20 %

Operating conditions

Maximum operating temperature
40 °C
Operating temperature
0 - 40 °C
Operating humidity
0 - 95%
Max. noise level
55 dB
Protection type (IP code)
IP20

Battery properties

Battery category
Industry battery
Battery
Rechargeable battery
Battery type
Lead–acid battery
Battery size
Device specific
Number of cells
1 x
Battery weight per cell
11700 g
Voltage
240 V
Capacity
367 Ah
Charging time
3 h
Operating time at full load
3.90 min
Operating time at half load
11.60 min

Sustainability

Manufacturer commitment
SBTi

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
USB cable
Items per sales unit
1 x

Product dimensions

Height
432 mm
Weight
25 kg
Width
85 mm
Length
584 mm

Package dimensions

Length
81 cm
Width
60 cm
Height
25 cm
Weight
25 kg
