HPE DL20 Gen10 E-2336 1P 16G 4SFF Svr

Intel Xeon E-2336, 16 GB, Rack Server
Price in EUR including VAT, free shipping
Delivered between Fri, 11.7. and Tue, 22.7.
10 items in stock at supplier

Product details

The HPE DL20 Gen10 Server is a powerful and compact solution designed for a variety of applications in modern data centers. Featuring an Intel Xeon E-2336 processor with six cores, this server delivers high processing power and efficiency. It is housed in a 1U form factor, making it ideal for environments with limited space. With a pre-installed memory capacity of 16 GB DDR4 RAM and the ability to support up to 128 GB RAM, the DL20 Gen10 is flexible and scalable to meet the demands of growing data volumes. The support for up to four SFF drives allows for versatile storage customization, while the 800-watt power supply ensures reliable performance. The server is also equipped with modern Ethernet controllers that provide high network speeds.

  • Processor with 6 cores for improved multitasking performance
  • Support for up to 128 GB RAM for expanded memory capacity
  • Maximum storage capacity of 4 SFF drives for flexible storage solutions
  • High network speed with 1000 Mbit/s via integrated Ethernet controllers
  • Efficient power supply with 800 watts for stable operation.

Key specifications

Number of rack units
1 U
Processor type
Intel Xeon E-2336
Max. number of hard disks
4
Number of processors
1 x
RAM
16 GB
Operating system
Windows
Item number
42134912

General information

Manufacturer
HPE
Category
Servers
Manufacturer no.
P66394-421-1
Release date
15.1.2024

Hardware form factor

Design
Rack Server
Number of rack units
1 U

Processor

Processor type
Intel Xeon E-2336
Number of processors
1 x
Clock frequency
2.90 GHz
Number of processor cores
6 -Core
Max. turbo clock rate
4.80 GHz
L3 Cache
12 MB

Motherboard properties

Chipset
Intel C256

Memory

Memory type
DDR4-RAM
Max. memory slots
4
Memory configuration
1 x 16GB
RAM
16 GB
Max. RAM
128 GB
RAM speed
3200 MHz
RAM error correction
ECC

Data storage controller

RAID configuration
01105
Possible raid configuration
01105
Mass storage controller type
SATA III

Hard drive slots

Max. number of hard disks
4
Form factor
2.5"
Interface
SATA
Hard disk additional functions
Hot swapping

External interfaces

USB ports
USB-AUSB-C
Exact USB ports
USB-A 3.2 Gen 1 (3x)
Data ports
PS/2 (1x)
Connectivity
EthernetLAN

Network

Network connections
RJ45 (2x)
Ethernet controller
Broadcom BCM5720
Ethernet controller brand
Broadcom
Max. port speed
1000 Mbit/s

Graphics card properties

Graphics card model
Matrox G200e
Graphics chip (GPU)
Matrox
Dedicated graphics memory
0.02 GB

Video connections

Video connections
VGA (1x)

Optical drive properties

Optical drive type
No drive

Operating system

Operating system
Windows
Processor design
64-bit

Mains supply properties

Number of power supply units
1 x
Power
800 W
Max. number of power supply units
1

Origin

Country of origin
Japan

Sustainability

Manufacturer commitment
SBTi

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
382.20 mm
Width
434.60 mm
Height
43.20 mm
Weight
6 kg

Package dimensions

Length
68 cm
Width
57 cm
Height
25 cm
Weight
4 kg

14-day cancellation right
30-day right of return
24 Months statutory warranty
