Screw assortment for cover
Width: 3 mm (diameter)
Material: Metal
For use with: Spacial SBM enclosures

Three profiles for a width of 800 mm, two for the bus box (three screws for widths over 400 mm), and four for flat and access boxes (six screws for widths over 400 mm). The Spacial SBM industrial enclosures from Schneider Electric are available in three versions and designed for use in industrial facilities and construction applications. The wall-mounted enclosures feature a one-piece rectangular body with stitched channels on the front and two or three pre-drilled profiles for the installation of mounting plates and DIN rails on the back. The mounting holes have a diameter of 12.5 mm. The enclosure cover includes a polyurethane adhesive joint and two, three, four, or six screws with a half turn, depending on the version. An M6 x 16 grounding connection bolt is welded into the cover to provide a potential connection for the enclosure.

Features and benefits:

• 28 different sizes available, using accessories from the expansion box, with depths of 80 mm and 120 mm, with or without pre-installed FL21 cable entries.
• IP66 protection, meaning the enclosures are dust-tight and provide protection against strong water jets and rough seas.
• External mechanical impact resistance of up to IK10 (20 Joules), allowing the wall box to withstand a 5 kg object dropped from a height of 40 cm.
• Can be installed with a screwdriver.
• Direct mounting from the back or with external mounting brackets.
• Protected inside and out by gray (RAL 7035) painted polyester.
• Attractive and robust design to protect sensitive electronics.

Typical applications:
The Spacial SDB series from Schneider is suitable for use in underground garages, road and railway tunnels.
