Schneider Electric Casys OPB Box Fixed Frame NSYOPB6U5F

Manufacturer: Schneider Electric
Description: Casys OPB Box Fixed Frame
Type: NSYOPB6U5F
Mounting Level: Front
Design: With fixed frame
Design of profile rail: Without
Number of doors: 1
Type of ventilation: Without
Width: 600 mm
Height: 380 mm
Depth: 500 mm
Grid dimension: 482.6 mm (19 inches)
Number of height units (U): 6
Max. load capacity: 50 kg
With roof plate: Yes
With grounding: No
With front door: Yes
With side walls: Yes
Disassemblable: Yes
Material: Steel
Surface finish: Powder-coated
Color: Gray
RAL number: 7035
Protection class (IP): IP20
Protection class (NEMA): 1

This Actassi OPB is a wall-mounted enclosure made of folded and welded steel sheet, powder-coated, leather-textured, RAL 7035 Light Gray Epoxy-Polyester. The enclosure consists of a body, two pivoting and removable side walls, fixed 19-inch rails, and a transparent Securit glass door with key number 333. Protection class against foreign bodies is IP20 and impact resistance is IK08 for the viewing door. Fixed 19-inch rack that can accommodate up to 3 kg per unit, with a maximum of 50 kg per enclosure according to IEC62208. The dimensions of this cabinet are 380 mm in height (or 6 U), 600 mm in width, and 500 mm in depth. Product family Actassi.
