StarTech Industrial 8 Port Gigabit PoE Switch - - Power Over Ethernet Switch - GbE PoE+ Unmanaged Switch -
8 portsPrice in EUR including VAT
free shipping
Rugged PoE Switch | 30 Watt | IP-30 Aluminum Housing | Unmanaged | 8 Port
This 8-port industrial-grade Gigabit PoE switch provides 30 W of power and is designed to be mounted in harsh environments, supporting a total power output of 200 W. It includes hardware for DIN rail or wall mounting.
For demanding environments where fiber connections are not required.
With Cat 5e (or higher) Ethernet cabling, this Ethernet switch provides up to 30 W of PSE power per PoE port on IEEE 802.3af (PoE/Type 1) and IEEE 802.3at (PoE+/Type 2) PD devices such as cameras, sensors, and WLAN access points.
It features a high total power budget with a high PoE port count, providing a maximum of 30 watts per port for a total of up to 200 watts. Power is provided according to the order of device connections, totaling a maximum of six 802.3at (30 W) devices (180 W total) at any one time.
Truly industrial-grade for devices that must operate in harsh conditions, this switch includes:
This Ethernet switch supports additional capabilities such as redundant power inputs, surge protection up to 2 kV on the RJ45 ports, and an MTBF of more than 500,000 hours (Telcordia/Bellcore) at 50°C for long-term reliability.
The StarTech.com Advantage:
Max. port speed | 1000 Mbit/s |
Network connections | RJ45 (8x) |
Switchtype | DIN Rail Switch, PoE Switch |
Number of PoE ports | 8 ports |
Management | Unmanaged |
Switch functions | PoE |
Item number | 18018145 |
Manufacturer | StarTech |
Category | Network switches |
Manufacturer no. | IESC1G80UP |
Release date | 22.9.2021 |
External links |
Colour | Black |
Exact colour description | Black |
Switchtype | DIN Rail Switch, PoE Switch |
Number of ports | 8 ports |
Number of PoE ports | 8 ports |
PoE Standard | 802.3at (PoE+) |
PoE budget | 200 W |
Management | Unmanaged |
Switch functions | PoE |
Switching capacity | 16000 Gbit/s |
Manufacturer Type | IESC1G80UP |
Network connections | RJ45 (8x) |
Max. port speed | 1000 Mbit/s |
Max. port speed RJ45 | 1000 Mbit/s |
Max. Port speed | 1000 Mbps / 1 Gbps |
Application range | Network |
Network operation | Powered device |
Power consumption | 206 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | Terminal strip |
Length | 14.20 cm |
Width | 10.50 cm |
Height | 3.96 cm |
Weight | 536 g |
