The RS2423+ is a versatile and cost-effective 2U 12-bay storage server for centralized data storage and sharing, endpoint and server backup, surveillance management, and other business applications. It offers over 3,500/1,700 MB/s sequential read/write performance.
Max. number of hard disks | 12 |
Memory | 8 GB |
NAS HDD assembly | NAS Empty Enclosure |
Total storage capacity | 0.03 TB |
RAID configuration | 0, 1, 10, 5, 6, C |
Network connections | RJ45 (3x) |
Exact USB ports | USB-A 3.0 (2x) |
Item number | 24453440 |
Manufacturer | Synology |
Category | NAS |
Manufacturer no. | RS2423+ |
Release date | 3.3.2023 |
External links |
Colour | Black |
Exact colour description | Black / Grey |
NAS HDD assembly | NAS Empty Enclosure |
Model | 19" rack |
Rack Unit | 2U |
Max. number of hard disks | 12 |
Hard drive form factor | 3.5" |
RAID configuration | 0, 1, 10, 5, 6, C |
Memory type | DDR4-RAM |
Memory | 8 GB |
Maximum possible memory | 32 GB |
NAS features – model-specific | VPN server max. 5 clients |
Data storage configuration | 0 TB |
Total storage capacity | 0.03 TB |
Hard disk additional functions | Hot swapping |
Processor type | AMD Ryzen Embedded V1780B |
Clock frequency | 3.35 GHz |
Max. turbo clock rate | 3.60 GHz |
Number of processor cores | 4 -Core |
Network connections | RJ45 (3x) |
Connectivity | LAN |
USB ports | USB-A |
Exact USB ports | USB-A 3.0 (2x) |
Video connections | HDMI (1x) |
Internal connection options | PCI Express x8 (1x) |
Number of camera licenses included | 2 x |
Power consumption | 120 W |
Power consumption (standby) | 46 W |
Number of fans | 3 x |
Fan diameter | 60 mm |
Redundant power supply unit | No |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | AC Cables |
Length | 55.20 cm |
Width | 55.20 cm |
Height | 8.80 cm |
Weight | 11.50 kg |
Length | 70 cm |
Width | 57 cm |
Height | 22 cm |
Weight | 10 kg |
