The wall-mounted enclosures of the Unique series have been designed for user-friendly installation of active and passive network components, as well as for clean cabling. Each cabinet is made from up to 1.5 mm thick steel sheet, providing excellent stability as a robust steel construction. Wall mounting is straightforward and can be completed quickly. The installation occurs in two steps: the rear panel of the enclosure is screwed to the wall and then connected to the enclosure. Optionally, the enclosures can also be installed freestanding with separately available leveling feet or wheels. The door and side panels can be easily disassembled, and a door hinge change can be made. The roof is prepared for the installation of a fan module for active ventilation. Each wall enclosure includes a pair (2 pieces) of mounted 483 mm (19") profile rails inside (enclosures from 600 mm depth include two pairs). These are galvanized, marked with height units (countable in both directions), and adjustable in depth. An important aspect of installation is cable management. Each cabinet's roof features a sliding cable entry with a rubber seal. The rear panel and base plate are equipped with punched cable entries with plastic covers. A comprehensive range of accessories for cable management, shelves, etc., is available to meet many everyday practical requirements.
Type | Cabinet |
Usable installation depth | 370 mm |
Protection type (IP code) | IP40 |
Ventilation | Passive |
Server cabinet features | Door, Lockable, Removable side panels, Safety glass |
Item number | 220045 |
Manufacturer | Digitus |
Category | Server cabinets |
Manufacturer no. | DN-19 09-U |
Release date | 25.10.2007 |
Sales rank in Category Server cabinets | 35 of 2225 |
Colour | Grey |
Exact colour description | Grey |
Material group | Metal |
Material | Steel |
Type | Cabinet |
Rack size | 19 inch rack |
Form factor size | 9 RU |
Usable installation depth | 370 mm |
Max. weight | 100 kg |
Protection type (IP code) | IP40 |
Wall thickness | 1.10 mm |
Ventilation | Passive |
Server cabinet features | Door, Lockable, Removable side panels, Safety glass |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 19" mounting screws |
Height | 491 mm |
Width | 600 mm |
Length | 450 mm |
Weight | 22.50 kg |
Length | 65 cm |
Width | 50 cm |
Height | 53.50 cm |
Weight | 15 kg |
