Fujitsu Primergy TX2550 M5

Intel Xeon Silver 4214, 16 GB, Tower Server
Currently out of stock
Free shipping starting at 30,–

Product details

The Fujitsu Server Primergy TX2550 M5 is a new dual-socket tower server featuring the latest technology, designed for excellent workload flexibility in enterprises, as well as scalability and high cost efficiency. With its combination of Intel Xeon Processor Scalable Family CPUs, 1.5 TB 2,933 MT/s DDR4, and Intel Optane DC Persistent Memory, it is ideal for most CPU- and memory-intensive workloads. It supports up to 32 storage drives, NVMe capability, cutting-edge RAID, and high-throughput network options, catering to collaboration and IT infrastructure workloads, as well as high data transfer workloads. Up to 8 expansion slots allow for future growth, while highly efficient, redundant power supplies enhance reliability and provide preemptive savings. The iRMC S5 enables optimal management throughout the entire lifecycle.

Key specifications

Number of rack units
4 U
Processor family
Xeon
Processor type
Intel Xeon Silver 4214
Max. number of hard disks
8
Number of processors
1 x
RAM
16 GB
Operating system
No operating system
Item number
13310617

General information

Manufacturer
Fujitsu
Category
Servers
Manufacturer no.
VFY:T2555SC030IN
Release date
9.6.2020

Hardware form factor

Design
Tower Server
Number of rack units
4 U

Processor

Processor family
Xeon
Processor type
Intel Xeon Silver 4214
Number of processors
1 x
Number of processor sockets
1 x
Clock frequency
2.20 GHz
Number of threads
24
Number of processor cores
12 -Core
Max. turbo clock rate
3.20 GHz
Max. TDP
85 W
L3 Cache
16.50 MB

Motherboard properties

Socket
LGA 3647
Chipset
Intel C624

Memory

Memory type
DDR4-RAM
Max. memory slots
12
Memory configuration
1 x 16GB
RAM
16 GB
Max. RAM
1500 GB
RAM speed
2933 MHz
RAM error correction
ECC
RAM buffer
Error Correcting Code

Data storage controller

RAID configuration
0110550660
Possible raid configuration
0110550660

Hard drive slots

Max. number of hard disks
8
Storage capacity
2.93 GB
Form factor
2.5"3.5"
Interface
SASSATA
Hard disk additional functions
Hot swapping

Internal interfaces

PCI express version (max.)
3
Internal connection options
PCI Express x16 (1x)PCI Express x8 (1x)

External interfaces

USB ports
USB-A
Connectivity
Ethernet

Network

Network connections
RJ45 (2x)
Max. port speed
1000 Mbit/s

Graphics card properties

Hardware interface
EthernetRJ45USB 2.0USB 3.0

Video connections

Video connections
VGA (1x)

Optical drive properties

Optical drive type
No drive

Operating system

Operating system
No operating system
Processor design
64-bit

Mains supply properties

Number of power supply units
1 x
Power
450 W
input voltage
230 V
Max. number of power supply units
1

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Length
774 mm
Width
177 mm
Height
448 mm
Weight
35.50 kg

Package dimensions

Length
108 cm
Width
60 cm
Height
40 cm
Weight
26 kg
