If there is enough space around the part to be removed, we recommend a 3-arm puller from the 30-S series for optimal load distribution. It features narrow puller hooks that are infinitely adjustable on the head, allowing for space-saving work with two arms. The parallel puller hooks can be positioned in any position, even under full load. The mechanical spindle has a rolled thread that is specially coated to enhance durability. This product is characterized by a robust design, high performance, and a long service life, with quality made in Germany. It includes anti-counterfeiting protection through a safety label and a self-healing corrosion protection KUKKoating on galvanized parts.

Application: This puller is ideal for removing bearings, gears, discs, etc., in tight and hard-to-reach spaces.

Advantage: It can be optionally converted to different puller hooks, and the variable clamping depth can be adjusted with puller hook extensions available up to puller size -20. The collar of the spindle head prevents the key from slipping, and the head has a hexagonal profile for counter-holding. It can be used as both an external and internal puller by rotating the puller hooks, making it suitable for removing asymmetrical workpieces. Stability support is provided by the optionally available clamp from the 219 series. All components are available as spare parts, with time-saving ordering through numbering. A tube of KUKKO special grease for the pressure spindle is included.

Further technical features:

• Weight: 3.005 kg
• Maximum internal clamping width: 220 mm
• Minimum internal clamping width: 100 mm
• Maximum external clamping width: 160 mm
• Maximum torque: 88.5 ft lb
• Outer hexagon: 22 mm.
